Specifications Model Number: ATV-3150DX-2 Engine Type: 150CC Single cylinder, 4-stroke, air-cooled Max Torque: 7.8 / 6500 (N.m/r/min) Max Horsepower: 6.0 / 8000 (Kw/r/min) Bore Stroke: 57.4 x 57.8 mm Ignition: CDI Starting System: Electric Battery: 12V, 9Ah Clutch: CTV Automatic Transmission: Chain, Foot Brakes Front/Rear: Hub/hydraulic disc Tires Front/Rear: 23 x 7 - 10 / 22 x 10 - 10 Fuel Capacity/Oil Type: 90#/0.9L Weight: G.W./N.W :193KG /170KG Wheelbase (Front/Rear): 1215mm Dimensions: 1870 x 1010 x 1060 mm Height to Seat: 620mm Min. Ground Clearance: 165mm
